• Under the 4 bolts which secure the wheel (1)
using the Torx TX40 spanner.
• Remove the wheel from the hub.
• Reassembly takes place in the reverse order.
ATTENTION: Danger of injury if the wheels come off!
If the drive wheels are insufficiently attached during assembly, they can come off during
driving.
• Tighten the TX40 countersunk screws to 30 Nm when mounting the drive wheels.
• Always use new screws with undamaged coating.
Note
Refit the wheel in reverse order.
Please ensure that the wheel is re-fitted on the same side and in the same running direction as
removed.
