Goodrive200 inverters Function codes
112
Function
code
Name
Detailed instruction of parameters
Default
value
adjustor to carry out integral adjustment on the
deviation of PID feedback and reference.
When the deviation of PID feedback and
reference is 100%, the integral adjustor works
continuously after the time (ignoring the
proportional effect and differential effect) to
achieve the Max. Frequency (P00.03) or the
Max. Voltage (P04.31). Shorter the integral time,
stronger is the adjustment
Setting range: 0.01~10.00s
P09.06
This parameter determines the strength of the
change ratio when PID adjustor carries out
integral adjustment on the deviation of PID
feedback and reference.
If the PID feedback changes 100% during the
time, the adjustment of integral adjustor (ignoring
the proportional effect and differential effect) is
the Max. Frequency (P00.03) or the Max. Voltage
(P04.31). Longer the integral time, stronger is the
adjusting.
Setting range: 0.00~10.00s
0. 00s
This parameter means the sampling cycle of the
feedback. The modulator calculates in each
sampling cycle. The longer the sapling cycle is,
the slower the response is.
Setting range: 0.000~10.000s
0.100s
deviation
limit
The output of PID system is relative to the
maximum deviation of the close loop reference.
As shown in the diagram below, PID adjustor
stops to work during the deviation limit. Set the
function properly to adjust the accuracy and
0.0% ○
