INVT GD200-037G/045P-4 - P10 Group: Simple PLC and Multi-step Speed Control

Goodrive200 inverters Function codes
115
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P09.14
Proportion
al gain at
low
frequency
(Kp)
0.00~100.00 1.00 ○
P09.15
PID
command
of
ACC/DEC
time
0.0~1000.0s 0.0s ○
P09.16
PID output
filter time
0.000~10.000s 0.000s
○
P10 Group Simple PLC and multi-step speed control
P10.00
Simple
PLC
0: Stop after running once. The inverter has to be
commanded again after finishing a cycle.
1: Run at the final value after running once. After
finish a signal, the inverter will keep the running
frequency and direction of the last run.
2: Cycle running. The inverter will keep on
running until receiving a stop command and then,
the system will stop.
0 ○
P10.01
Simple
PLC
memory
0: Power loss without memory
1:Power loss memory；PLC record the running
step and frequency when power loss.
0 ○
P10.02
Multi-step
speed 0
100.0% of the frequency setting corresponds to
the Max. frequency P00.03.
When selecting simple PLC running, set
P10.02~P10.33 to define the running frequency
and direction of all steps.
Note: The symbol of multi-step determines the
0.0% ○
P10.03
The
running
time of
step 0
0.0s ○
