INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Function codes
117
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
speed 6
16 steps speed via the combination code of S1,
S2, S3, and S4.
The start-up and stopping of multi-step running is
determined by function code P00.06, the
relationship between S1,S2,S3,S4 terminals and
multi-step speed is as following:
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Step
0
1
2
3
4
5
6
7
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
Setting range of P10.(2n,1<n<17):
-100.0~100.0%
Setting range of
P10.(2n+1,1<n<17):0.0~6553.5s(min)
P10.15
The
running
time of
step 6
0.0s ○
P10.16
Multi-step
speed 7
0.0% ○
P10.17
The
running
time of
step 7
0.0s ○
P10.18
Multi-step
speed 8
0.0% ○
P10.19
The
running
time of
step 8
0.0s ○
P10.20
Multi-step
speed 9
0.0% ○
P10.21
The
running
time of
step 9
0.0s ○
P10.22
Multi-step
speed 10
0.0% ○
P10.23
The
running
time of
step 10
0.0s ○
P10.24
Multi-step
speed 11
0.0% ○
