Goodrive200 inverters Function codes
129
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
S5 S4 S3 S2 S1
Range: 0000~00FF
P17.13
ON-OFF
output
terminals
state
Display current Switch output terminals state of
the inverter
BIT3 BIT2 BIT1 BIT0
RO2 RO1 HDO Y
Range: 0000~000F
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
inverter.
Range : 0.00Hz~P00.03
●
P17.15
torque
reference
Display the torque given, the percentage to the
current rated torque of the motor.
Setting range: -300.0%~300.0%
(the rated current of the motor)
●
P17.16
Linear
speed
Display the current linear speed of the inverter.
Range: 0~65535
●
P17.17
Length
Display the current length of the inverter.
Range: 0~65535
●
P17.18
Counting
value
Display the current counting number of the
inverter.
Range: 0~65535
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00~10.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00~10.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00~10.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.000~50.000kHz
●
P17.23
PID
reference
Display PID reference value
Range: -100.0~100.0%
●
