INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Function codes
128
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P16 Group Ethernet function
P17 Group Monitoring function
P17.00
Setting
frequency
Display current set frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.01
Output
frequency
Display current output frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the
inverter
Range: 0.00Hz~P00.03
●
P17.03
Output
voltage
Display current output voltage of the inverter
Range: 0~1200V
●
P17.04
Output
current
Display current output current of the inverter
Range: 0.0~3000.0A
●
P17.05
Motor
speed
Display the rotation speed of the motor.
Range: 0~65535RPM
●
P17.06
Reserved
●
P17.07
Reserved
●
P17.08
Motor
power
Display current motor power
Range:-300~300%
●
P17.09
Output
torque
Display the current output torque of the inverter.
Range: -250.0~250.0%
●
P17.10
Evaluated
motor
frequency
Evaluated frequency of motor rotor
Range: 0.00Hz~ P00.03
●
P17.11
DC bus
voltage
Display current DC bus voltage of the inverter
Range: 0.0~2000.0V
●
P17.12
ON-OFF
input
terminals
state
Display current Switch input terminals state of the
inverter
BIT8
BIT7
BIT6
BIT5
HDI S8 S7 S6
BIT4
BIT3
BIT2
BIT1
BIT0
●
