INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
140
Function
code
Name Detailed instruction of parameters
Default
value
P03.04 Speed loop integral time 2
0.000~10.000s 0.200s
P03.05
High switching
frequency
P03.02~P00.03(the Max. frequency) 10.00Hz
P03.06 Speed loop output filter
0~8 (corresponds to 0~2
8
/10ms) 0
P03.07
Compensation coefficient
of electromotion slip
50%~200% 100%
P03.08
Compensation coefficient
of braking slip
50%~200% 100%
P03.09
Current loop percentage
coefficient P
0~65535 1000
P03.10
Current loop integral
coefficient 1
0~65535 1000
P03.11 Torque setting method
1:Keypad setting torque(P03.12)
2:Analog AI1 setting torque
3:Analog AI2 setting torque
4:Analog AI3 setting torque
5:Pulse frequency HDI setting torque
6:Multi-step torque setting
7:MODBUS communication setting
torque
8~10:Reserved
0
P03.12 Keypad setting torque
-300.0%~300.0%
(rated current of the motor)
50.0%
P03.13
Torque reference filter
time
0.000~10.000s 0.010s
P03.14
Upper frequency of
forward rotation in vector
control
0:Keypad (P03.16 sets P03.14,P03.17
sets P03.15)
1: AI1
2: AI2
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
0
P03.15
Upper frequency of
reverse rotation in vector
control
0
