INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
145
Function
code
Name
Detailed instruction of parameters Default
value
on model
P00.12 DEC time 1 0.0~3600.0s
Depend
on model
P02.02 Rated frequency of AM 1 0.01Hz~P00.03(the Max. frequency)
50.00
Hz
P02.04 Rated voltage of AM 1
0~1200V 380V
P04.00 Motor 1 V/F curve setting
0:Straight line V/F curve；applying to the
constant torque load
1:Multi-dots V/F curve
2:1.3
th
power low torque V/F curve
3:1.7
th
power low torque V/F curve
4:2.0th power low torque V/F curve
5:Customized V/F(V/F separation)
0
P04.01 Motor 1 torque boost
0.0%:(automatic)0.1%~10.0% 0.0%
P04.02 Motor 1 torque boost close
0.0%~50.0%
(the rated frequency of motor 1)
20.0%
P04.03 V/F frequency 1
of motor 1
0.00Hz~P04.05 0.00Hz
P04.04 V/F voltage 1 of motor 1
0.0%~110.0% 00.0%
P04.05 V/F
frequency 2 of motor 1
P04.03~ P04.07 00.00Hz
P04.06 V/F voltage 2 of motor 1
0.0%~110.0% 00.0%
P04.07 V/F
frequency 3 of motor 1
P04.05~ P02.02 00.00Hz
P04.08 V/F voltage 3 of motor 1
0.0%~110.0% 00.0%
P04.09
V/F slip compensation
gain of motor 1
0.0~200.0% 0.0%
P04.10
Motor 1 low frequency
vibration control factor
0~100 10
P04.11
Motor 1 high frequency
vibration control factor
0~100 10
P04.12
Motor 1 vibration control
threshold
0.00Hz~P00.03 (the Max. frequency) 30.00 Hz
P04.26 Energy-saving operation 0: No action 0
