INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
148
Function
code
Name Detailed instruction of parameters
Default
value
reverse rotation in
vector control
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
frequency
7~9: Reserved
P03.16
Keypad setting for
upper frequency of
forward rotation
0.00Hz~P00.03 (the Max. frequency) 50.00 Hz
P03.17
Keypad setting for
upper frequency of
reverse rotation
0.00 Hz~P00.03 (the Max. frequency) 50.00 Hz
P03.18
Upper
electromotion
torque
source
0:Keypad setting upper-limit frequency(P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5:MODBUS communication
6~8: Reserved
0
P03.19
Upper braking
torque
source
0
P03.20
Keypad setting of
electromotion
torque
0.0~300.0%( rated current of the motor) 180.0%
P03.21
Keypad setting of
braking torque
0.0~300.0%( rated current of the motor) 180.0%
P17.09
Output torque -250.0~250.0% 0.0%
P17.15
Torque reference
-300.0~300.0%( rated current of the motor) 0.0%
