INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
173
Function
code
Name Detailed instruction of parameters
Default
value
P05.00 HDI input type selection
0:HDI is high pulse input
1:HDI is switch input
0
P05.01 S1 terminal function
selection
0: No function
1: Forward rotation operation (FWD)
2: Reverse rotation operation (REV)
3: 3-wire control operation (Sln)
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10:Increasing frequency setting(UP)
11:Decreasing frequency setting(DOWN)
12:Cancel the frequency change setting
13:Shift between A setting and B setting
14:Shift between combination setting
and A setting
15:Shift between combination setting
and B setting
16:Multi-step speed terminal 1
17:Multi-step speed terminal 2
18:Multi-step speed terminal 3
19:Multi- step speed terminal 4
20:Multi- step speed pause
21:ACC/DEC time option 1
22:ACC/DEC time option 2
23:Simple PLC stop reset
24:Simple PLC pause
25:PID control pause
26:Traverse Pause
(stop at the current frequency)
1
P05.02 S2 terminal function
selection
4
P05.03 S3 terminal function
selection
7
P05.04 S4 terminal function
selection
0
P05.05 S5 terminal function
selection
0
P05.06 S6 terminal function
selection
0
P05.07 S7 terminal function
selection
0
P05.08
S8 terminal function
selection
0
P05.09
HDI terminal function
selection
0
