Goodrive200 inverters Basic operation instruction
Function Instructions
time.
10 Upper-limit frequency arrival
Output ON signal when the running frequency of the
inverter is the upper limit frequency.
11 Lower-limit frequency arrival
Output ON signal when the running frequency of the
inverter is the lower limit frequency.
12 Ready
When the main circuit and the control circuit are
established and the protection function of the
inverter is not active. The inverter is in the running
state and it will output ON signal.
13 In pre-exciting Output ON signal during pre-exciting
14 Overload pre-alarm
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.08~P11.10 for the
detailed instruction.
15 Underload pre-alarm
Output ON signal if the inverter is beyond the
pre-alarm point. Refer to P11.11~P11.12 for the
detailed instruction.
16 Simple PLC step completion
Output signal if the simple PLC step is completed.
17 Simple PLC cycle completion
Output signal if the 1 simple PLC cycle is
completed.
18 Set counting arrival
Output ON signal if the detected counting exceeds
the set value of P08.25.
19 Fixed counting arrival
Output ON signal if the detected counting exceeds
the set value of P08.26.
20 External fault valid Output ON signal if external fault occurs.
21 Length arrival
Output ON signal if the actual detected length
exceeds the se length by P08.19.
22 Running time arrival
Output ON signal if the accumulative running time
of the inverter exceeds the setting time by P08.27.
23
MODBUS communication
virtual terminal output
Output corresponding signal according to the
setting value of MODBUS. Output ON signal if the
setting value is 1 and output OFF signal if the
setting value is 0.
24~25 Reserved
