Goodrive200 inverters Basic operation instruction
191
Function
code
Name Detailed instruction of parameters
Default
value
unless it reaches the internal integral
limit. When the trend between the
reference and the feedback changes, it
needs more time to offset the impact of
continuous working and the integration
will change with the trend.
1: Stop integral adjustment when the
frequency achieves the upper and low
limit. If the integration keeps stable, and
the trend between the reference and the
feedback changes, the integration will
change with the trend quickly.
LED tens: P00.08 is 0
0: The same with the setting direction; if
the output of PID adjustment is different
from the current running direction, the
internal will output 0 forcedly.
1:Opposite to the setting direction
LED hundreds: P00.08 is 0
0: Limit to the maximum frequency
1: Limit to frequency A
LED thousands:
0:A+B frequency, the buffer of A
frequency is invalid
1:A+B frequency, the buffer of A
frequency is valid
ACC/DEC is determined by ACC time 4
of P08.04
P17.00
Set frequency
0.00Hz~P00.03 (the Max. frequency)
0.00Hz
P17.23 PID reference value
-100.0~100.0% 0.0%
P17.24 PID feedback value -100.0~100.0% 0.0%
