INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Keypad operation procedure
38
No.
Name
Description
forward rotation state; LED on means
the inverter is in the reverse rotation
state
LOCAL/REMOT
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the inverter is in the
keypad operation state; LED blinking
means the inverter is in the terminals
operation state; LED on means the
inverter is in the remote communication
control state.
TRIP
LED for faults
LED on when the inverter is in the fault
state; LED off in normal state; LED
blinking means the inverter is in the
pre-alarm state.
2
Unit
LED
Mean the unit displayed currently
Hz Frequency unit
RPM Rotating speed unit
A Current unit
% Percentage
V Voltage unit
3
Code
displayi
ng zone
5-figure LED display displays various monitoring data and alarm code such
as set frequency and output frequency.
Displayed
word
Correspo
nding
word
Displayed
word
Correspo
nding
word
Displayed
word
Correspo
nding
word
0 1 2
3 4 5
6 7 8
