INVT GD200-037G/045P-4 - Page 67

Goodrive200 inverters Function codes
66
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
of reverse
rotation in
vector
control
frequency
7~ 9: Reserved
Note: Setting method 1~9, 100% corresponds to
the maximum frequency
P03.16
Keypad
setting for
upper
frequency
of forward
rotation
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range:0.00 Hz~P00.03 (the Max. output
frequency)
50.00 Hz
○
P03.1
7
Keypad
setting for
upper
frequency
of reverse
rotation
50.00Hz
○
P03.18
Upper
electro
motion
torque
source
This function code is used to select the electro
motion and braking torque upper-limit setting
source selection.
0:Keypad setting upper-limit frequency
(P03.20 sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5:MODBUS communication
6~8: Reserved
Note: setting mode 1~9,100% corresponds to
three times of the motor current.
0 ○
P03.19
Upper
braking
torque
source
0 ○
