Goodrive200 inverters Function codes
65
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
coefficient
1
P03.11
Torque
setting
method
This parameter is used to enable the torque
control mode, and set the torque.
0:Torque control is invalid
1:Keypad setting torque(P03.12)
2:Analog AI1 setting torque
3:Analog AI2 setting torque
4:Analog AI3 setting torque
5:Pulse frequency HDI setting torque
6:Multi-step torque setting
7:MODBUS communication setting torque
8~10:Reserved
Note: Setting modes 2~10, 100% corresponds to
three times of the rated current of the motor.
0 ○
P03.12
Keypad
setting
torque
Setting range: -300.0%~300.0%(rated current of
the motor)
50.0%
○
P03.13
Torque
reference
filter time
0.000~10.000s 0.010s
○
P03.14
Upper
frequency
of forward
rotation in
vector
control
0:Keypad
(P03.16 sets P03.14,P03.17 sets P03.15)
1: AI1
2: AI2
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
0 ○
P03.15
Upper
frequency
0 ○
