Goodrive200 inverters Function codes
64
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
system. Adjust on the base of PI according to
different loads to meet various demands.
The setting range of P03.00:0~200.0
The setting range of P03.01: 0.000~10.000s
The setting range of P03.02:0.00Hz~P03.05
The setting range of P03.03:0~200.0
The setting range of P03.04: 0.000~10.000s
The setting range of P03.05:P03.02~P00.03(the
Max. output frequency)
P03.06
Speed loop
output filter
0~8 (corresponds to 0~2
8
/10ms) 0 ○
P03.07
Compensa
tion
coefficient
of electro
motion slip
Slip compensation coefficient is used to adjust
the slip frequency of the vector control and
improve the speed control accuracy of the
system. Adjusting the parameter properly can
control the speed steady-state error.
Setting range:50~200%
100%
○
P03.08
Compensa
tion
coefficient
of braking
slip
100%
○
P03.09
Current
loop
percentage
coefficient
P
Note:
1 These two parameters adjust the PI adjustment
parameter of the current loop which affects the
dynamic response speed and control accuracy
directly. Generally, users do not need to change
the default value.
2 Only apply to SVC control mode 0(P00.00=0).
Setting range:0~65535
1000 ○
P03.10
Current
loop
integral
1000 ○
