Goodrive200 inverters Function codes
75
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
selection
25:PID control pause
26:Traverse Pause(stop at the current frequency)
27:Traverse reset(return to the center frequency)
28:Counter reset
29:Torque control prohibition
30:ACC/DEC prohibition
31:Counter trigger
32:Length reset
33:Cancel the frequency change setting
temporarily
34:DC brake
35:Reserved
36:Shift the command to the keypad
37:Shift the command to the terminals
38:Shift the command to the communication
39: Pre-exciting command
40:Clear the power
41:Keep the power
42~60:Reserved
61: PID pole switching
62~63:Reserved
P05.10
Polarity
selection of
the input
terminals
The function code is used to set the polarity of
the input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT0
BIT1
BIT2
BIT3
BIT4
S1 S2 S3 S4 S5
BIT5
BIT6
BIT7
BIT8
S6 S7 S8 HDI
The setting range:0x000~0x1FF
0x000
○
P05.11
ON-OFF Set the sample filter time of S1~S8 and HDI 0.010s
○
