Goodrive200 inverters Function codes
74
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P04.35
Reserved
●
P05 Group Input terminals
P05.00
HDI
input
0: HDI is high pulse input. See P05.49~P05.54
1: HDI is switch input
0 ◎
P05.01
S1
terminal
function
selection
0: No function
1: Forward rotation
2: Reverse rotation
3: 3-wire control
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10:Increasing frequency setting(UP)
11:Decreasing frequency setting(DOWN)
12:Cancel the frequency change setting
13:Shift between A setting and B setting
14:Shift between combination setting and A
setting
15:Shift between combination setting and B
setting
16:Multi-step speed terminal 1
17:Multi-step speed terminal 2
18:Multi-step speed terminal 3
19:Multi- step speed terminal 4
20:Multi- step speed pause
21:ACC/DEC time option 1
22:ACC/DEC time option 2
23:Simple PLC stop reset
24:Simple PLC pause
1 ◎
P05.02
S2 terminal
function
selection
4 ◎
P05.03
S3 terminal
function
selection
7 ◎
P05.04
S4 terminal
function
selection
0 ◎
P05.05
S5 terminal
function
selection
0 ◎
P05.06
S6 terminal
function
selection
0 ◎
P05.07
S7 terminal
function
selection
0 ◎
P05.08
S8 terminal
function
selection
0 ◎
P05.09
HDI
terminal
function
0 ◎
