Goodrive200 inverters Function codes
81
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
time
P05.29
S8
terminal
switching-o
ff delay
time
0.000s
○
P05.30
HDI
terminal
switching-o
n delay
time
0.000s
○
P05.31
HDI
terminal
switching-o
ff delay
time
0.000s
○
P05.32
L
ower limit
of AI1
The function code defines the relationship
between the analog input voltage and its
corresponding set value. If the analog input
voltage beyond the set minimum or maximum
input value, the inverter will count at the minimum
or maximum one.
When the analog input is the current input, the
corresponding voltage of 0~20mA is 0~10V.
In different cases, the corresponding rated value
of 100.0% is different. See the application for
detailed information.
The figure below illustrates different applications:
0.00V
○
P05.33
Correspon
ding
setting of
the lower
limit of
AI1
0.0% ○
P05.34
Upper limit
of AI1
10.00V
○
P05.35
Correspon
ding
setting of
the upper
limit of AI1
100.0%
○
P05.36
AI1 input 0.100s
○
