INVT GD200-037G/045P-4 - P06 Group: Output Terminals

Goodrive200 inverters Function codes
83
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
middle
setting of
AI3
The setting range of P05.45:-100.0%~100.0%
The setting range of P05.46:P05.44~10.00V
The setting range of P05.47:-100.0%~100.0%
The setting range of P05.48:0.000s~10.000s
P05.46
Upper limit
of AI3
10.00V
○
P05.47
Correspon
ding
setting of
the upper
limit of AI3
100.0%
○
P05.48
AI3 input
filter time
0.100s
○
P05.49
HDI
high-
speed
pulse input
The function selection when HDI terminals is
high-speed pulse input
0:Frequency setting input, frequency setting
source
1:Counter input, high-speed pulse counter input
terminals
2:Length counting input, length counter input
terminals
0 ◎
P05.50
L
ower limit
frequency
of HDI
0.000kHz~P05.52
0.000
kHz
○
P05.51
Correspon
ding
setting of
HDI low
frequency
setting
-100.0%~100.0% 0.0% ○
P05.52
Upper limit
frequency
P05.50 ~50.00kHz
50.00
kHz
○
