Goodrive200 inverters Function codes
87
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P06.16
HDO
high-
speed
pulse
output
selection
2:Ramp reference frequency
3:Running rotation speed
4:Output current
(relative to twice the inverter rated current)
5:Output current
(relative to twice the motor rated current)
6:Output voltage
7:Output power
8:Reserved
9:Output torque
10:Analog AI1 input value
11:Analog AI2 input value
12:Analog AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16~21:Reserved
22: Torque current
(relative to triple the motor rated current)
23: Ramp reference frequency(with sign)
24~30 :Reserved
0 ○
P06.17
L
ower limit
of AO1
output
The above function codes define the relative
relationship between the output value and analog
output. When the output value exceeds the range
of set maximum or minimum output, it will count
according to the low-limit or upper-limit output.
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
Please refer to each application for detailed
0.0% ○
P06.18
Correspon
ding AO1
output to
the lower
limit
0.00V
○
P06.19
Upper limit
of AO1
100.0%
○
