INVT GD200-037G/045P-4 - Page 89

Goodrive200 inverters Function codes
88
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
output information.
10V (20m A)
0 .0% 1 00.0 %
A O
Setting range of P06.18 0.00V~10.00V
Setting range of P06.19 P06.17~100.0%
Setting range of P06.20 0.00V~10.00V
Setting range of P06.21 0.000s~10.000s
Setting range of P06.22 0.0%~P06.24
Setting range of P06.23 0.00V~10.00V
Setting range of P06.24 P06.22~100.0%
Setting range of P06.25 0.00V~10.00V
Setting range of P06.26 0.000s~10.000s
Setting range of P06.27 0.000s~10.000s
Setting range of P06.28 0.00~50.00kHz
Setting range of P06.29 P06.27~100.0%
Setting range of P06.30 0.00~50.00kHz
Setting range of P06.31 0.000s~10.000s
P06.20
The
correspond
ing AO1
output to
the upper
limit
10.00V
○
P06.21
AO
1 output
filter time
0.000s
○
P06.22
L
ower limit
of AO2
output
0.0% ○
P06.23
Correspon
ding AO2
output to
the lower
limit
0.00V
○
P06.24
Upper limit
of AO2
output
100.0%
○
P06.25
Correspon
ding AO2
output to
the upper
limit
10.00V
○
P06.26
AO2 output
filter time
0.000s
○
P06.27
L
ower limit
of HDO
output
0.00%
○
P06.28
Correspon 0.00kHz
○
