INVT GD200-037G/045P-4 - Page 93

Goodrive200 inverters Function codes
92
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
BIT2:bus voltage (Hz on)
BIT3:output voltage(V on)
BIT4:output current(A on)
BIT5:running rotation speed (rpm on)
BIT6:output power(% on)
BIT7:output torque(% on)
BIT8:PID reference(% flickering)
BIT9:PID feedback value(% on)
BIT10:input terminals state
BIT11:output terminals state
BIT12:torque set value(% on)
BIT13:pulse counter value
BIT14:length value
BIT15:PLC and the current stage in multi-step
speed
P07.06
Parameter
s state 2
0x0000~0xFFFF
BIT0: AI1 (V on)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency given value(Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9: upper limit frequency (Hz on)
BIT10~15:reserved
0x0000
P07.07
The
parameter
in
the stop
state
0x0000~0xFFFF
BIT0:set frequency
(Hz on, frequency flickering slowly)
BIT1:bus voltage (V on)
0x00FF
○
