Goodrive200 inverters Function codes
93
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
BIT2:input terminals state
BIT3:output terminals state
BIT4:PID reference (% flickering)
BIT5:PID feedback value(% flickering)
BIT6:reserved
BIT7:analog AI1 value(V on)
BIT8:analog AI2 value(V on)
BIT9: analog AI3 value(V on)
BIT10:high speed pulse HDI frequency
BIT11:PLC and the current step in multi-step
speed
BIT12:pulse counters
BIT13:length value
BIT14: upper limit frequency (Hz on)
BIT15:reserved
P07.08
F
requency
coefficient
0.01~10.00
Displayed frequency=running frequency* P07.08
1.00 ○
P07.09
Rotation
speed
coefficient
0.1~999.9%
Mechanical rotation speed =120*displayed
running frequency×P07.09/motor pole pairs
100.0%
○
P07.10
Linear
speed
coefficient
0.1~999.9%
Linear speed= Mechanical rotation
speed×P07.10
1.0% ○
P07.11
Rectifier
bridge
module
temperatur
e
0~100.0℃ ●
P07.12
Converter
module
temperatur
0~100.0℃ ●
