INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-156-
Function
code
Name Description Default
Modify
103: Manual soft startup for motor H
104: Di
sable motor A
105: Disable motor B
106: Disable motor C
107: Disable motor D
108: Disable motor E
109: Disable motor F
110: Disable motor G
111: Disable motor H
P05.07
Reserved
P05.08
Input terminal
polarity
Used to set the polarity of input terminals.
When a bit is 0, the input terminal is pos
itive;
when a bit is 1, the input terminal is negative.
0x000±0x3F
0x000 ƻ
P05.09
Digital input filter
time
Used to specify the filter time of S1
±
S4 and HDIA
terminal sampling. In strong interference cases,
increase the value to avoid maloperation.
0.000±1.000s
0.010s ƻ
P05.10
Virtual terminal
setting
0x000
±0x3F (0: Disable. 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: Reserved
0x00 Ƽ
P05.11
Terminal control
mode
Used to set the mode of terminal control.
0: Two
-wire control 1, the enabling consistent
with the direction. This mode is widely used. The
defined FWD/REV terminal command
determines the motor rotation direction.
FWD
REV
COM
K1
K2
Running
command
FWD REV
OFF OFF
OFF
OFF
ON
ON
ON ON
Stop
Hold
Forward
running
Reverse
running
0 Ƽ
