INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-218-
Function
code
Name Description Default
Modify
P26.02
Y2 output
0
ƻ
P26.03
Y3 output
0
ƻ
P26.04
RO3 output
0
ƻ
P26.05
RO4 output
0
ƻ
P26.06
RO5 output
0
ƻ
P26.07
RO6 output
0
ƻ
P26.08
RO7 output
0
ƻ
P26.09
RO8 output
0
ƻ
P26.10
RO9 output
0
ƻ
P26.11
RO10 output
0
ƻ
P26.12
Expansion card
output terminal
polarity
0x0000
±0x7FF
5252«52+'2<<LQVHTXHQFH
0x000 ƻ
P26.13
HDO2 switch-on
delay
Used to specify the delay time corresponding to
the
electrical level changes when the
programmable output terminals switch on or
switch off.
Si Electrical
level
Si Valid
Invalid Invalid
Switch-on
delay
Switch-off
delay
Valid
Setting range: 0.000
±50.000s
Note:
P26.13 and P26.14 are valid only when
P26.00
=1.
0.000s ƻ
P26.14
HDO2 switch-off
delay
0.000s ƻ
P26.15
Y2 switch-on delay
0.000s
ƻ
P26.16
Y2 switch-off delay
0.000s
ƻ
P26.17
Y3 switch-on delay
0.000s
ƻ
P26.18
Y3 switch-off delay
0.000s
ƻ
P26.19
RO3 switch-on delay
0.000s
ƻ
P26.20
RO3 switch-off delay
0.000s
ƻ
P26.21
RO4 switch-on delay
0.000s
ƻ
P26.22
RO4 switch-off delay
0.000s
ƻ
P26.23
RO5 switch-on delay
0.000s
ƻ
P26.24
RO5 switch-off delay
0.000s
ƻ
P26.25
RO6 switch-on delay
0.000s
ƻ
P26.26
RO6 switch-off delay
0.000s
ƻ
P26.27
RO7 switch-on delay
0.000s
ƻ
P26.28
RO7 switch-off delay
0.000s
ƻ
P26.29
RO8 switch-on delay
0.000s
ƻ
P26.30
RO8 switch-off delay
0.000s
ƻ
P26.31
RO9 switch-on delay
0.000s
ƻ
P26.32
RO9 switch-off delay
0.000s
ƻ
P26.33
RO10 switch-on
0.000s
ƻ
