Goodrive270 series VFD for fan and pump Basic operation guidelines
-60-
Name Description Default
P04.32±100.0% (of the motor rated voltage)
0.0%±P04.31 (motor rated voltage)
P04.33
in constant power
1.00±1.30 1.00
P04.34
Pull-
V/F control
When the SM VF control mode is enabled, the
function code is used to set the reactive current of
the motor when the output frequency is lower than
the frequency specified by P04.36.
Setting range: -100.0%±
100.0% (of the motor rated
current)
20.0%
P04.35
Pull-
V/F control
When the SM VF control mode is enabled, the
function code is used to set the reactive current of
the motor when the output frequency is hi
the frequency specified by P04.36.
Setting range: -100.0%±
100.0% (of the motor rated
current)
10.0%
P04.36
Frequency threshold
for pull-in current
switching in SM V/F
control
When the SM VF control mode is enabled, the
function code is used to set the frequency threshold
for the switching between pull-in current 1 and
pull-in current 2.
Setting range: 0.00Hz±P00.03 (Max. output
50.00Hz
P04.37
Reactive current
closed-loop
proportional
coefficient in SM V/F
When the SM VF control mode is enabled, the
function code is used to set the proportional
coefficient of reactive current closed-loop control.
Setting range: 0±3000
50
P04.38
Reactive current
closed-loop integral
time in SM V/F control
When the SM VF control mode is enabled, the
function code is used to set the integral coefficient
of reactive current closed-loop control.
30
P04.39
Reactive current
closed-loop output
limit in SM VF control
When the SM VF control mode is enabled, the
function code is used to set the output limit of the
reactive current closed-
loop control. A greater value
indicates a higher reactive closed-loop
compensation voltage and higher output power of
the motor. In general, you do not need to modify the
8000
