Goodrive30 Series VFD Function parameter list
-84-
amplitude of wobbling frequency P08.15.
Sudden jump frequency＝Amplitude of wobbling
frequency AW ×Amplitude of sudden jump
frequency (P08.16), that is, the value that the
sudden jump frequency corresponds to the
wobbling frequency when the VFD runs at the
wobbling frequency.
Rise time of wobbling frequency: Time needed
for the VFD to run from the lowest point to the
highest one.
Fall time of wobbling frequency: The time
needed for the VFD to from the highest point to
the lowest one.
Setting range of P08.15: 0.0–100.0% (relative to
the set frequency)
Setting range of P08.16: 0.0–50.0% (relative to
the amplitude of wobbling frequency)
Setting range of P08.17: 0.1–3600.0s
Setting range of P08.18: 0.1–3600.0s
The counter works by the input pulse signals of S
terminal (set as "Counter trigger") or HDI (set
P05.00 to 1).
When the designated counting value is reached,
the multi-function output terminals will output the
signal of "Designated counting value reached "
and the counter go on working; when the set
counting value is reached, the multi-function
output terminals will output the signal of "The set
counting value reached", the counter will clear all
counting values and stop to recount until the next
pulse comes.
The setting counting value P08.26 shall be no
more than the setting counting value P08.25.
The function is illustrated as follows.
Designated
counting
value
