INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-86-
Function
code
Name
Description
Default
Modify
P08.34
FDT2
electrical
level
detection
value
Time
t
Output frequency f
FDT
electrical
level
FDT lag
Y, RO1,
RO2
Setting range of P08.32: 0.00Hz–P00.03 (Max.
output frequency)
Setting range of P08.33: 0.0–100.0% (FDT1
electrical level)
Setting range of P08.34: 0.00Hz–P00.03 (Max.
output frequency)
Setting range of P08.35: 0.0–100.0% (FDT2
electrical level)
50.00Hz
○
P08.35
FDT2
lagging
detection
value
5.0%
○
P08.36
Detection
value for
frequency
being
reached
When the output frequency is within the
detection range, the multi-function digital output
terminal outputs the signal of "Frequency
reached".
Y,
RO1, RO2
Output
frequency
Set
frequency
Detection amplitude
Time t
Time t
Setting range: 0.00Hz–P00.03 (max output
frequency)
0.00Hz
○
P08.37
Enabling
energy
consumptio
n braking
The function code is used to control enabling of
the brake tube action inside the VFD.
0: Disable
1: Enable
Note: It is onlyapplicable to VFD models that are
built in braking tubes.
0
○
