Chapter 1 BEFORE USING THE MACHINE
Air Intake Filter Cleaning
Clean the air intake filter at least once a month in order to be able to use the
machine in good conditions.
1. Raise the operation panel as
shown in the figure.
2. Hold the both end of the filter
case, and pull it out.
3. Remove the air intake filter from
the filter case and wash the filter.
4. Dry the filter, and return it into the
filter case.
Then, set it to the main body.
SR-2000α User’s Manual (No. 0000A) 1-11
