Chapter 1 BEFORE USING THE MACHINE
1.4 PAPER ROLL INSTALLATION
1. Raise the Thermal Head Cover,
and pull the Cassette to draw out of
the main body.
Confirm that the paper
roll can turn gently with
the space from 0.5 to
2mm between the roll
and the Roll Stopper.
2. Load a new paper roll around the
Roll Holder and raise the roll
stopper to fix the roll position.
3. Pass the paper end 1 through 3
as shown in the figure.
4. Slide the label guide to fit the paper
width.
1-8 SR-2000α User’s Manual (No. 0000A)
