Chapter 5 PROGRAMING MODE
PLU Data Registration 3/3
Entry examples are shown below. Select necessary registration items to enter.
Item Operation
Example: Department code “3”
Example: Group code “2”
Example: Item code “7232”
Touch on the screen to access to the selection screen
Then, touch one of the following buttons to select.
When referring to the reference data setting
When the unit type is not required.
Example: Upper weight limit “8.950 lb”
Example: Lower weight limit “8.500 lb”
5-10 SR-2000α User’s Manual (No. 0000A)
To Next Page
