JCM TAIKO - External Dimensions; External Dimensions When Installing Type1;Type2;Type3 Faceplate

16
7-4. External Dimensions
7-4-1. External Dimensions when installing Type1/Type2/Type3 Faceplate
18
9847.2
42.7 (Door Installation Position)
88
17.6
51
(Bill Ejection Position)
3.2
2 to 6mm (Panel Thickness)
100
103 (Door Installation Position)
124
83
(Max. Bill Width 82)
19 66
4-M4
50
Unit:mm
Top
Right Side
Bottom
Front Rear
A*
* The length of A differs depending
on the faceplate type.
Type1: 68(Min. Bill Width 67)
Type2: 76(Min. Bill Width 75)
Type3: 71(Min. Bill Width 70)
