4-5
TAIKO Service Manual
CHAPTER
4
© 2006 Japan Cash Machine Co.Ltd. All rights reserved.
4-2. Writing Serial No.
This section provides writing Serial No. instructions for the TAIKO with PC. When replacing
the CPU board, perform writing Serial No. to TAIKO. Serial No. data disappears with
replaced CPU board.
4-2-1. Requirements
When writing serial No. to the TAIKO Unit, the following items are required.
- PC (OS:Windows 98 SE/2000/XP)
- TAIKO Unit
- TAIKO Harness Download adapter ( EDP#:G00172 )
- Writing Serial No. Software Program (SerialNo.exe)
- JCM Power Supply Unit and
- TAIKO Harness for MIB 232 or UAC (EDP#:G00176 +G00183
- When the TAIKO Unit is installed to the Host Machine, the Power
Supply Unit (A1 , B1), the TAIKO Harness A ( A2) and the VM-450
Connection Harness( B2) are not required.
To Next Page
