TAIKO Service Manual
2-12
CHAPTER
2
© 2006 Japan Cash Machine Co., Ltd.. All rights reserved.
2-4-2. When installing the Type5 faceplate with TAIKO unit
25.4
20
45 98
‚2㨪6mm(Panel Thickness)
38.3 (Door Installation Position)
88
51(Bill Ejection Position)
3
125
103
(Door Installation Position)
100
67
(Acceptable Bill Width 66)
11.4
39.6
30
Unit:mm
Top
Right Side
Bottom
Front Rear
