JCM TAIKO - External Dimensions When Installing Type5 Faceplate

17
7-4-2. External Dimensions when installing Type5 Faceplate
25.4
20
45 98
‚2㨪6mm(Panel Thickness)
38.3 (Door Installation Position)
88
51(Bill Ejection Position)
3
125
103
(Door Installation Position)
100
67
(Acceptable Bill Width 66)
11.4
39.6
30
Unit:mm
Top
Right Side
Bottom
Front Rear
