JCM TAIKO - ID-001 (Parallel) Specification

TAIKO Service Manual
2-6
CHAPTER
2
© 2006 Japan Cash Machine Co., Ltd.. All rights reserved.
Pin No.
Sign al
Name
I/O *1 Function
1 VCC - 12V DC Power Supply
2 VCC - 12V DC Power Supply
3 VSS - Power Supply GND
4 NC - Not Connected
5 ACK ACK signal receive line
6 REJ REJ signal receive line
7 INH INH signal receive line
8 VALID VALID signal send line
9 VEND1 VEND1 signal send line
10 VEND2 VEND2 signal send line
11 VEND3 VEND3 signal send line
12 NC - Not Connected
13 NC - Not Connected
14 BUSY BUSY signal send line
15 ABN ABN signal send line
16 STKF STKF signal send line
IN
OUT
OUT
2-2-2-1. Interface Connector Pin Assignments
01: ID-001 (parallel) Specification
*1 Conditions for the I/O (Input/Output) column are from the Bill Acceptor side.
