5-4. Cleaning
If the paper dust or foreign object spotted in the acceptor parts, the acceptance rate may go
down. Clean the acceptor parts once a month. Wipe out on the sensor with lint-free cloth
or cotton bud. Remove the paper dust or foreign object completely on the rollers.
- DO NOT use the organic solvent such as thinner or benzin,
when wiping the TAIKO unit.
Sensors/Rollers Location
ԘSensor
ԙPinch Roller
ԚFeed Roller
ԛMagnetic Sensor (For only Pub-11)
Ԛ
Ԙ
ԙ
Ԙ
ԙ
Ԙ
Ԙ
Ԙ
Open Upper Lid
Open Lower Lid
Ԙ
Ԙ
Ԛ
Ԙ
ԙ
ԛ
