JCM TAIKO - When Installing the Type1;Type2;Type3 Faceplate with TAIKO Unit

2-11
TAIKO Service Manual
© 2006 Japan Cash Machine Co., Ltd. All rights reserved.
CHAPTER
2
2-4. External Dimensions
2-4-1. When installing the Type1/Type2/Type3 faceplate with TAIKO unit
18
9847.2
42.7 (Door Installation Position)
88
17.6
51
(Bill Ejection Position)
3.2
2 to 6mm (Panel Thickness)
100
103 (Door Installation Position)
124
83
(Max. Banknote Width 82)
19 66
4-M4
50
Unit:mm
Top
Right Side
Bottom
Front Rear
A*
* The length of A differs depending on the faceplate type.
Type1: 68(Min. Banknote Width 67)
Type2: 76(Min. Banknote Width 75)
Type3: 71(Min. Banknote Width 70)
