4-5. Cloning
Using the Clone Harness, the software can be copied from the Master TAIKO Unit to
Salve TAIKO Unit. (Cloning)
4-5-1. Required Items
When cloning, the following items are required.
- TAIKO Unit installed the cloning feature applicable software (Master)
- TAIKO Unit to copy the software (Slave)
- Clone Harness (Part#: 3280-05-52, EDP#: 124528)
- JCM Power Supply Unit *1
- TAIKO Harness A *2
- VM-450 Connection Harness *2
*1,2 Use a test bench and a harness instead of the power supply. A test bench and a harness
to be decided by each specification. To identify each specification, refer to following
table.
A.ID-003/MDB/Pulse/ccTalk
A1:JCM Power Supply Unit(Part#: VM-30, EDP#: 116125) or equivalent
A2:TAIKO Harness A(Part#: 3280-05-54, EDP#: 127527)
B.ID-001
B1:JCM Power Supply Unit(Part#: VM-450, EDP#: 059307) or equivalent
B2:VM-450 Connection Harness(Part#: 3280-05-102, EDP#: N/A)
- For the cloning features applicable software, refer to the Software
Information Sheet.
- When the TAIKO Unit is installed to the Host Machine, the Power
Supply Unit (A1 , B1), the TAIKO Harness A ( A2) and the VM-450
Connection Harness( B2) are not required.
Interface
OperationLabel
(Interface)
Interface
Connector
Option
Connector
ID‑001 01 White No
X4 Black Yes
ID‑003
MDB
Pulse
ccTalk
