5-3-8. Entrance Flapper Test Procedure
Test the entrance flapper.
1. Set the switch Nos.1, 4 and 5 ON and turn the power to the TAIKO unit.
2. Set the switch No.1 OFF to start the test. Then the entrance flapper repeates open/
close operation.
3. If the Blue LED lamp lights, no error is found.
- If TAIKO’s red LED lamp lights, the Entrance Flapper has a
problem.
5-3-9. Exit Flapper Test Procedure
Test the exit flapper.
1. Set the switch Nos.1, 2, 4 and 5 ON and turn ON the power to the TAIKO unit.
2. Set the switch No.1 OFF to start the test. Then the exit flapper repeates open/close
operation.
3. If the Blue LED lamp lights, no error is found.
- If TAIKO’s red LED lamp lights, the Exit Flapper has a prob-
lem. Please contact your nearest distributor or our sales rep-
resentative. See=> 5-7. Productt Support
