4-1. Download
The software download procedure is described in this section. When the software has been
upgraded or the TAIKO Unit’s CPU board has been replaced, please download the soft-
ware to the TAIKO Unit.
When downloading a software from Palm, please refer 4-4. Palm.
4-1-1. Requirements
When downloading, the following items are required.
- PC (OS:Windows 98 SE/2000/XP)
- TAIKO Unit
- TAIKO Harness B (Part#: 3280-03-11, EDP#: 116488)
- Downloader (Download Program Ver. 1.21.exe)
- Software Program
- JCM Power Supply Unit *1
- TAIKO Harness A *2
- VM-450 Connection Harness *2
*1,2 Use a test bench and a harness instead of the power supply. A test bench and a harness
to be decided by each specification. To identify each specification, refer to following
table.
A.ID-003/MDB/Pulse/ccTalk
A1:JCM Power Supply Unit(Part#:VM-30,EDP#: 116125) or ( MIB232,EDP#G00176 )
A2:TAIKO Harness A(Part#: VM-30,EDP#: 127527)or ( G00182-ID0E3; G00183-ID003)
B.ID-001
B1:JCM Power Supply Unit(Part#: VM-450, EDP#: 059307) or equivalent
B2:VM-450 Connection Harness
- When the TAIKO Unit is installed to the Host Machine, the Power
Supply Unit (A1 , B1), the TAIKO Harness A ( A2) and the VM-450
Connection Harness are not required.
Interface
OperationLabel
(Interface)
Interface
Connector
Option
Connector
ID‑001 01 White No
X4 Black Yes
ID‑003
MDB
Pulse
ccTalk
