Preface
© 2006 Japan Cash Machine Co.Ltd. All rights reserved.
Product Configurations
TAIKO unit’s are configured as follows.
[Model] PUB-
* [Type] *** - * * * * - **
A B C D E F G
A. V
alidation Method 7: Optical/Transparency/Reflection
11: Optical/Transparency/Reflection/MAG
B. Country Code ISO based 3-digit codes
C. Faceplate Type 0: Withdout faceplate
1: Acceptable Bill Width Max. 82mm/ Min. 67mm
2: Acceptable
Bill Width Max.82mm/ Min. 75mm
3: Acceptable
Bill Width Max.82mm/ Min. 70mm
5: Acceptable Bill Width 66mm
D. Optional Unit
0: Without optional unit
1: With interface pin assignment conversion harness
(ccTalk-compatible)
2: ID-001 Interface Type (Upper tray for 16PIN connector)
3: Individual
E. Board Type 1: Standard
2: Interface pin assignment (ccT
alk-compatible)
3: Parallel Interface type
F. Operation Code 0: Standard
G
. Interface X4: SERIAL(ID-003)/MDB/PULSE/ccTalk
01 : ID-001 (parallel)
Example: PUB-7 EUR-1020-X4
Indicates the
TAIKO model Bill Acceptor with Optical/Transparency Reflection
Type, Type 1 faceplate, Euro software, no optional unit, interface pin assignment
(ccTalk-compatible) type board, standard operation code, and an Serial(ID-003)/
MDB/Pulse/ccTalk interface.
