Chapter 5 Configuring the Meter
Configure – Channel Plan Tab
88 DSAM Help User Guide Rev. 001
AutoTests Use the Select an AutoTest screen to configure how AutoTests func-
tion using the active channel plan.
At least one DOCSIS channel must be enabled in your active channel
plan before you can conduct a Cable Modem AutoTest or Home Certi-
fication test.
Configuring AutoTest
for Cable Modem
To configure AutoTest for cable modems
1 Press Configure.
2 Press the Chan Plan softkey.
3 Using the arrow keys, select AutoTests.
4 Press ENTER.
NOTE
When you configure an AutoTest, the parameters apply only to the
current active plan. Other channel plans require their own AutoTest
configuration.
Figure 75 Configure – Channel Plan Tab: Autotests
