Chapter 9 Measure Mode – Service Tab
DOCSIS
218 DSAM Help User Guide Rev. 001
– Packets sent and lost
– Average round trip time
– Loss to sent ratio
To run a ping test
1 Press the View softkey.
2 Using the arrow keys, select Ping.
3 Press ENTER.
4 Using the arrow keys, select the IP Address option.
5 Press ENTER.
6 Using the arrow keys, select the IP address you want to ping.
7 Press ENTER.
8 Using the arrow keys, select Packet Size (bytes).
9 Press ENTER.
10 Using the arrow keys, select the packet size you want to send.
11 Press ENTER.
Figure 196 Measure Mode – DOCSIS Ping Test
NOTE
To add, modify or delete an IP address, see “Adding Ping IP
Addresses” on page 220, “Modifying Ping IP Addresses” on
page 220, or “Deleting Ping IP Addresses” on page 221.
21128026 R001 DSAM Help User Guide.book Page 218 Thursday, February 5, 2009 2:02 PM
