Chapter 10 Measure Mode – Spectrum Tab
Ingress Resistance
DSAM Help User Guide Rev. 001 267
3 Using the arrow keys, select Ingress Resistance.
4 Press ENTER.
5 Use the left and right arrow keys to move the marker in 0.1 MHz
increments.
6 Use the up and down arrows to adjust the graph for best viewing
of the signal level measurements.
Figure 244 Spectrum – Ingress Resistance
Figure 245 Spectrum – Ingress Resistance
NOTE
With each non-continuous key press, the marker moves to the next
or previous frequency point in the span. A continual press moves
the marker faster.
21128026 R001 DSAM Help User Guide.book Page 267 Thursday, February 5, 2009 2:02 PM
