Setting the alarms for the rst time
1. On the home screen, tap the Isolation Mode quick link.
2. On the ROOM screen, expand Isolation Mode and choose from the following options:
• Positive
• Negative
• Neutral
3. Optional: If you have a secondary monitored space, tap Secondary and expand Isolation Mode to choose the isolation mode for
the secondary monitored space.
4. To conrm the new settings, tap the Checkmark icon. The home screen appears.
5. On the home screen, tap the Settings icon.
6. On the SETTINGS screen, tap Analog I/O.
7. To nd the analog input you want to set up the alarm for, swipe left.
8. Scroll down and tap the Alarm Setup arrow.
9. Switch Alarm Enabled on.
10. Tap the High Alarm Setpoint arrow.
11. Enter the High Alarm Setpoint and tap the Checkmark to conrm your settings.
12. Tap the High Warning Limit arrow.
13. Enter the High Warning Limit and tap the Checkmark to conrm your settings.
14. Tap the Low Warning Limit arrow.
15. Enter the Low Warning Limit and tap the Checkmark to conrm your settings.
Note: If you congure your space for both positive and negative isolation mode, repeat this process and set up an alarm for the positive
and the negative isolation mode.
Changing the alarm limits
1. On the home screen, tap the Settings icon.
2. On the SETTINGS screen, tap Analog I/O.
3. To nd the analog input you want to set up the alarm for, swipe left.
4. Scroll down and tap the Alarm Setup arrow.
5. Switch Alarm Enabled on.
6. Tap the High Alarm Setpoint arrow.
7. Enter the High Alarm Setpoint and tap the Checkmark to conrm your settings.
8. Tap the High Warning Limit arrow.
9. Enter the High Warning Limit and tap the Checkmark to conrm your settings.
10. Tap the Low Warning Limit arrow.
11. Enter the Low Warning Limit and tap the Checkmark to conrm your settings.
Naming the pressure analog input
Set the name you want to appear on the home screen for a certain analog input. If you set up the FMS-2000C controller in portrait mode
you can have 16 characters. In landscape mode, you can have 12 characters.
1. On the home screen, tap the Settings icon.
2. On the SETTINGS screen, tap Analog I/O.
3. To nd the analog input you want to set up a name for, swipe left.
4. Scroll down and tap the Name arrow.
5. Enter a name for the analog input and tap the Checkmark icon to conrm it.
