Johnson Controls FMS-2000C - Technical Specifications; Controller Specifications Summary

FMS-2000C
LIT-12013504
61
Intended use
Indoor use
Overvoltage category
II
Altitude
Up to 2000 m
Pressure range
± 0.2500 in. W.C.
Alarm range
± 0.2500 in. W.C.
Display range
± 0.2500 in. W.C.
Accuracy
± 0.5% full scale
Air flow sensor type
Digital differential pressure features no offset, zero drift and is hysteresis free
Flow control resolution
± 0.0010 in. W.C.
Displayed pressure resolution
± 0.0001 in. W.C.
Control capability
Up to 4 independent spaces
I/O Resources
4 universal inputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
2 thermistor inputs (NTC Type 2 or 3, 10K at 77° F)
4 digital inputs (active-high or active-low 0 VDC to 5 VDC or 0 VDC to 24 VDC)
4 universal outputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
4 relay outputs (NO or NC contacts 1A at 24 VDC)
Operating temperature
32°F to 125°F (0°C to 52°C)
Operating humidity
10% to 95% relative humidity, non-condensing
Mounting
Thin mount for shallow wall cavities, surface mount for mounting to standard single-gang wall box
Alarm indication
360° Safety Halo color coded visual, audible alarm
Alarm silence
Touchscreen, auto-reset
Password protection
Up to 50 user passwords with 2 access levels (administrator and restricted)
Communications protocol
BACnet MS/TP (to BAS) 76.8k, 38.4k, 19.2k, 9600 baud, Metasys N2 open
Power requirement
24 VAC (nominal, 20 VAC minimum/28 VAC maximum), 50/60 Hz 30 VA power supply, Class 2,
Limited Energy, or LPS
Power consumption 30 VA maximum
Optional input power supply
Universal 120 VAC/240 VAC-to-24 VAC, 30 VA step-down isolation transformer
24 VAC-to-24 VAC, 30 VA isolation transformer
Display resolution
720 pixels x 1280 pixels
Pluggable screw terminal blocks
18 AWG to 22 AWG (1.0 mm to 0.6 mm diameter)
Display dimensions
(height x width x depth)
5.3 in. x 3.5 in. x 1.17 in. (134.62 mm x 88.9 mm x 29.72 mm)
Mounted depth
0.58 in. (14.73 mm)
Controller dimensions
(height x width x depth)
6.56 in. x 5.5 in. x 1.88 in. (166.62 mm x 139.7 mm x 47.75 mm)
Power supply enclosure dimensions
(height x width x depth)
5 in. x 4.7 in. 2.3 in. (127 mm x 119.38 mm x 58.42 mm)
Compliance United States
UL Listed to UL 61010-1; FCC 47CFR Part 15; BTL Listed
Canada
cUL Listed to CAN/CSA C22.2 NO. 61010-1; ICES-003
Europe
CE (EMC Directive) to EN 61326-1
Australia and New
Zealand
RCM Mark (Australian Radiocommunications Act) to EN 61326-1
Technical specications
