Johnson Controls FMS-2000C User Manual

FMS-2000C
LIT-12013504
46
Conguring the trigger mode for Isolation Mode
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to congure the trigger mode for, swipe left.
4. On the RELAY screen, expand Trigger Mode and tap Isolation Mode. See Table 6 for more information.
5. To conrm the new setting, collapse Trigger Mode.
Adjusting the type of isolation mode
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to adjust the type of isolation mode for, swipe left.
4. On the RELAY screen, expand Isolation Mode and choose from the following options:
• Positive
• Negative
• Neutral
5. To conrm the new setting, collapse Isolation Mode.
Conguring the action mode
In direct acting mode, the alarm relay activates when the sensor input exceeds the high setpoint and deactivates when the sensor input
falls below the low setpoint. In reverse acting mode, the alarm relay activates when the sensor input falls below the low setpoint and
deactivates when the sensor input exceeds the high setpoint.
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to congure the action mode for, swipe left.
4. On the RELAY screen, expand Action Mode and choose from the following options:
• Direct Acting
• Reverse Acting
5. To conrm the new setting, collapse Action Mode.
Setting up a delay
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to set up a delay for, swipe left.
4. On the RELAY screen, expand Action Mode and move the slider to set a delay time of up to 180 seconds.
5. Optional: Tap the Revert icon to revert back to the previous delay time.
6. To conrm the new setting, collapse Action Mode.
Conguring the action mode
In direct acting mode, the alarm relay activates when the sensor input exceeds the high setpoint and deactivates when the sensor input
falls below the low setpoint. In reverse acting mode, the alarm relay activates when the sensor input falls below the low setpoint and
deactivates when the sensor input exceeds the high setpoint.
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to congure the action mode for, swipe left.
4. On the RELAY screen, expand Action Mode and choose from the following options:
• Direct Acting
• Reverse Acting
5. To conrm the new setting, collapse Action Mode.
Setting up a delay
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view relay settings, tap Relay.
3. To nd the relay you want to set up a delay for, swipe left.
4. On the RELAY screen, expand Action Mode and move the slider to set a delay time of up to 180 seconds.
5. Optional: Tap the Revert icon to revert back to the previous delay time.
6. To conrm the new setting, collapse Action Mode.
