Johnson Controls FMS-2000C User Manual

FMS-2000C
LIT-12013504
38
Enabling the alarm and changing the alarm limits for air ow
1. On the home screen, tap the Settings icon.
2. On the SETTINGS screen, tap Analog I/O.
3. To nd the analog input you want to set up the alarm for, swipe left.
4. Scroll down and tap the Alarm Setup arrow.
5. Switch Alarm Enabled on.
6. Tap the High Alarm Setpoint arrow.
7. Enter the High Alarm Setpoint and tap the Checkmark to conrm your settings.
8. Tap the High Warning Limit arrow.
9. Enter the High Warning Limit and tap the Checkmark to conrm your settings.
10. Tap the Low Warning Limit arrow.
11. Enter the Low Warning Limit and tap the Checkmark to conrm your settings.
Naming the air ow input
Set up a name for the analog input you want to appear on the home screen. If your FMS-2000C controller is in portrait mode, you can
have up to 16 characters. If your FMS-2000C controller is in landscape mode, you can have 12 characters.
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view analog input settings, tap Analog I/O.
3. To nd the analog input you want to set up a new name for, swipe left.
4. On the ANALOG screen, scroll down and tap the Name arrow.
5. On the Name screen enter a new name.
6. To conrm the new name, tap the Checkmark icon.
Conguring the analog inputs for volumetric o󰀨set control
Use volumetric o󰀨set control (VOC) when you want to maintain an o󰀨set setpoint between the total supply and total exhaust air ows
including any fume hoods in the monitored space. To congure for volumeteric o󰀨set control, congure both AI-3 and AI-4 for air ow.
Use AI-3 and AI-4 for total supply and total exhaust air ows respectively.
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view analog input settings, tap Analog I/O.
3. To congure AI-3 for ow, swipe left twice.
4. On the ANALOG 3 screen, tap the Type arrow.
5. On the Type screen, scroll to Flow and tap the Checkmark icon to conrm the new settings. Refer to Conguring the analog input
to measure air ow to complete the setup of AI-3.
6. To congure AI-4 for ow, swipe left three times.
7. On the ANALOG 4 screen, tap the Type arrow.
8. On the Type screen, scroll to Flow and tap the Checkmark icon to conrm the new settings. The volumetric o󰀨set switch appears
on the ANALOG 4 screen. Refer to Conguring the analog input to measure air ow to complete the setup of AI-4.
9. Switch volumetric o󰀨set on.
10. See Conguring the analog input to measure air ow to complete your setup for Volumetric O󰀨set.
Conguring the analog output for air ow control
If you are controlling ow, map the analog input to the corresponding analog output as required by the specic application. Refer to the
submittal package wiring diagrams to map the analog output correctly.
If you are controlling volumetric o󰀨set, map AI-3 and AI-4 to the corresponding analog outputs as required by the specic application.
To map the analog output, refer to the submittal package wiring diagrams. Use AO-3 for the supply valves and AO-4 for the general
exhaust.
Changing the operating mode for air ow control
Each of the four analog outputs of the FMS-2000C controller can be congured for the following operating modes:
• Direct operating mode
• PID operating mode
In direct operating mode, the output tracks the mapped analog input directly or inversely. The PID operating mode may or may not
employ the proportional-integral-derivative scheme for closed-loop control of the analog output. The range of the output can or cannot
include an o󰀨set. This is independent of the mode the analog output is congured to.
To change the operating mode, complete the following steps:
1. On the home screen, tap the Settings icon to enter the Settings menu.
2. To view analog input settings, tap Analog I/O.
3. To nd the analog output you want to change the operating mode for, swipe left.
4. On the ANALOG screen, tap Output.
5. To change the operating mode, expand Operating Mode arrow and tap Direct Analog or PID Analog.
6. Collapse Operating Mode to save the new settings.
